TP-LINK TL-SG105 - 5-port Metal Gigabit Switch 10/100/1000M RJ45 ports
€26.90
Le prix comprend la
TVA (20%)
€4.48
En stock
Détails du produit
TP-Link TL-SG105. Type de commutateur: Non-géré. Type de port Ethernet RJ-45 de commutation de base: Gigabit Ethernet (10/100/1000), Quantité de ports Ethernet RJ-45 de commutation de base: 5. Full duplex. Répertoire MAC: 2000 entrées, Capacité de commutation: 10 Gbit/s. Standards réseau: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. Connecteur d'alimentation: DC-in jack
Caractéristiques de gestion
Type de commutateur
What switch device has, managed or unmanaged.
Non-géré
Qualité de service (QoS)
Connectivité
Quantité de ports Ethernet RJ-45 de commutation de base
The number of basic switching RJ-45 Ethernet ports (sockets).
5
Type de port Ethernet RJ-45 de commutation de base
The type/category of basic switching RJ-45 Ethernet ports (sockets).
Gigabit Ethernet (10/100/1000)
Quantité de ports .Gigabit Ethernet (copper)
5
Connecteur d'alimentation
DC-in jack
Réseau
Standards réseau
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Soutien 10G
The product can use Oracle 10G, which is a database management system introduced in 2003.
Full duplex
A full-duplex system allows communication in both directions, and unlike half-duplex, allows this to happen simultaneously.
Assistance contrôle des flux
Auto MDI/MDI-X
A Medium Dependent Interface (MDI) describes the interface (both physical and electrical) in a computer network from a physical layer implementation to the physical medium used to carry the transmission. Ethernet over twisted pair also defines a medium dependent interface crossover (MDIX) interface. Auto-MDIX ports on newer network interfaces detect if the connection would require a crossover, and automatically chooses the MDI or MDIX configuration to properly match the other end of the link.
LAN Ethernet : taux de transfert des données
The different speed levels of the Ethernet LAN connection.
10,100,1000 Mbit/s
Négociation automatique
Transmition des données
Débit de transfert de données
Rates at which data can be transferred. May vary according to network configurations.
10/100/1000Mbps
Capacité de commutation
The data transfer capacity of the switch per second.
10 Gbit/s
Taux de transfert
7,4 Mpps
Répertoire MAC
The MAC address is the 'Media Access Control Address'. It is a unique address given to a network interface controller (NIC) in a device. A MAC address table shows the addresses in a table format.
2000 entrées
Enregistrement-et-réémission
Taux de transfert de données maximal
2 Gbit/s
Support de trames étendues (Jumbo Frames)
Trames géantes
16000
Mémoire cache de paquet
1 Mo
Sécurité
Filtrage IGMP
Protocoles
Protocole de commutation
CSMA/CD
Design
Couleur du produit
La couleur, p. ex. rouge, bleu, vert, noir, blanc.
Noir
Voyants
Certification
CE, FCC, RoHS
Puissance
Source d'alimentation
What is providing power for the product e.g. mains electricity.
CC
Bloc d'alimentation inclus
There is a power supply with this product.
Courant d'entrée
0.6 A
Tension d'entrée
The voltage (V) which is required to power the product.
9 V
Consommation (max)
The maximum amount of power used by the device.
2,43 W
PoE (alimentation via le port Ethernet)
Connexion Ethernet, supportant l'alimentation via ce port (PoE)
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
Conditions environnementales
Température d'opération
The minimum and maximum temperatures at which the product can be safely operated.
0 - 40 °C
Température hors fonctionnement
The minimum and maximum temperatures at which the product can be safely stored.
-40 - 70 °C
Humidité relative de fonctionnement (H-H)
10 - 90%
Taux d'humidité relative (stockage)
5 - 90%
Dissipation thermique
The heat expressed in British thermal units per hour; generated by the power supply
8,29 BTU/h
Poids et dimensions
Largeur
The measurement or extent of something from side to side.
99,8 mm
Profondeur
The distance from the front to the back of something.
97,8 mm
Hauteur
Height of the product
25 mm
Informations sur l'emballage
Guide d'utilisation
Type d'emballage
The type of product package e.g. box.
Boîte
Kit de montage en rack
Largeur du colis
The distance from one side of the packaging to the other.
128 mm
Profondeur du colis
The distance from the front to the back of the packaging.
125 mm
Hauteur du colis
The distance from the top to the bottom of the packaging.
92 mm
Autres caractéristiques
Technologie de connectivité
The technology that enables connectivity of the device, e.g. wired or wireless.
Avec fil
Wifi
Popular technology that allows an electronic device to exchange data or connect to the internet wirelessly using radio waves.
Voyant LED d'alimentation
Ethernet/LAN
An Ethernet LAN (Local Area Network) interface is present, for a wired conection via a cable.
